Code of Federal Regulations Title 49. Transportation § 49.299.333 Frog guard rails and guard faces; gauge
Current as of January 02, 2025 | Updated by Findlaw Staff
The guard check and guard face gages in frogs shall be within the limits prescribed in the following table:
|
Table 1 to § 299.333 |
||
|
Guard check gage |
||
|
The distance between the gauge line of a frog |
Guard face gage |
|
|
Track class |
to the guard line 1 of its guard rail or guarding face, measured across the track at right angles to the gauge line, 2 may not be less than— |
The distance between the guard lines,1 measured across the track at right angles to the gauge line, 2 may not be more than— |
|
H0-H7 |
1,393 mm |
1,358 mm. |
1 A line along that side of the flangeway which is nearer to the center of the track and at the same elevation as the gage line.
2 A line 14 mm (0.55 inches) below the top of the center line of the head of the running rail, or corresponding location of the tread portion of the track structure.
